| Model |
Capacity |
Drum Capacity |
Handle Length(Effective Max.) |
Winding Layer Number of Wire Rope |
| MAXPULL MR-1 |
100 kg |
5 mm x 35 m(6 Layers Winding) |
250 mm |
1st Layer: 143N (14.6 kgf) |
| 3rd Layer: 187N (19.0 kgf) |
| 4th Layer: 208N (21.2 kgf) |
| MAXPULL MR-3 |
300 kg |
6 mm x 32 m(6 Layers Winding) |
250 mm |
1st Layer: 76N (7.7 kgf) |
| 3rd Layer: 103N (10.5 kgf) |
| 5th Layer: 131N (13.3 kgf) |
| MAXPULL MR-5 |
500 kg |
6 mm x 40 m(6 Layers Winding) |
250 mm |
1st Layer: 109N (11.1 kgf) |
| 3rd Layer: 142N (14.4 kgf) |
| 5th Layer: 174N (17.7 kgf) |
| MAXPULL MR-10 |
1,000 kg |
8 mm x 35 m(5 Layers Winding) |
300 mm |
1st Layer: 133N (13.5 kgf) |
| 2nd Layer: 157N (16.0 kgf) |
| 3rd Layer: 182N (18.5 kgf) |
| MAXPULL MR-20 |
2,000 kg |
9 mm x 38 m(5 Layers Winding) |
370 mm |
1st Layer: 157N (16.0 kgf) |
| 2nd Layer: 186N (18.9 kgf) |
| 3rd Layer: 214N (21.8 kgf) |
| MAXPULL MR-30 |
3,000 kg |
12 mm x 35 m(4 Layers Winding) |
370 mm |
1st Layer: 137N (13.9 kgf) |
| 2nd Layer: 169N (17.2 kgf) |
| 3rd Layer: 201N (20.5 kgf) |
