| Model |
KOSHIN SE-50X |
KOSHIN SE-80X |
KOSHIN SE-50EX |
KOSHIN SE-80EX |
KOSHIN SE-100EX |
| Pump |
Connection Dia |
50 mm (2″) |
80 mm (3″) |
50 mm (2″) |
80 mm (3″) |
100 mm (4″) |
| Connection Thread |
Outer Pipe Thread BSP |
| Total Head |
30 m (98 ft) |
26 m (85 ft) |
28 m (92 ft) |
28 m (92 ft) |
27 m (89 ft) |
| Delivery Volume |
600 L/min (158 USG/min) |
930 L/min (246 USG/min) |
650 L/min (172 USG/min) |
1100 L/min (290 USG/min) |
1350 L/min (356 USG/min) |
| Max. Suction Head |
8 m (26 ft) |
| Engine |
Type |
Forced Air-cooled 4-stroke Gasoline Engine |
| Model |
Subaru EY15-3D |
Subaru EY20-3D |
Subaru EX16 |
Subaru EX17 |
Subaru EX27 |
| Exhaust Volume |
143 cc |
183 cc |
169 cc |
169 cc |
265 cc |
| Rated Output |
2.0 kW (2.7 PS) / 3600 rpm |
2.6 kW (3.5 PS) / 3600 rpm |
2.2 kW (3.0 PS) / 3600 rpm |
2.9 kW (4.0 PS) / 3600 rpm |
5.1 kW (7.0 PS) / 3600 rpm |
| Max. Output |
2.6 kW (3.5 PS) / 4000 rpm |
3.7 kW (5.0 PS) / 4000 rpm |
3.2 kW (4.3 PS) / 4000 rpm |
4.2 kW (5.7 PS) / 4000 rpm |
6.6 kW (9.0 PS) / 4000 rpm |
| Fuel |
Automotive Unleaded Gasoline |
| Fuel Tank Capacity |
2.8 L (0.74 USG) |
3.8 L (1.00 USG) |
3.2 L (0.84 USG) |
3.2 L (0.84 USG) |
5.6 L (1.48 USG) |
| Continuous Oparating Time |
Approx. 2.8 hrs |
Approx. 3 hrs |
Approx. 2.5 hrs |
Approx. 2.1 hrs |
| Starting Method |
Recoil Starter |
| Standard Accessories |
1 Strainer, 2 Hose Couplings, 3 Hose Bands, 1 Engine Tool Set |
| Gross Weight |
23 kg (50.7 lbs) |
35 kg (77.1 lbs) |
27 kg (59.5 lbs) |
33 kg (72.7 lbs) |
57 kg (125 lbs) |
| Dimensions LxWxH (mm) |
484 × 330 × 420 |
525 × 370 × 472 |
504 × 401 × 411 |
530 × 405 × 465 |
670 × 477 × 669 |
| Packing Unit |
1 |
