| Model |
REN-7524 |
RENS-7524 |
REL-7524 |
RES-7524 |
| Voltage |
DC 24 V |
| Voltage |
43 A |
| Motor Output |
750 W |
| Rating |
1 h / 43A |
| Roller Revolution |
100 rpm |
50 rpm (Low), 100 rpm (High) |
| Manual Max. Capacity |
Max. |
450 kg (150 A) |
900 kg (Low), 450 kg (High), (150 A) |
| Rating |
110 kg (43 A) |
220 kg (Low), 110 kg (High), (43 A) |
| Winch Speed(With 100 kg Load) |
33 m/min (108 ft/min) |
17 m/min (55 ft/min) (Low), 33 m/min (108 ft/min) (High) |
| Standard Accessories |
1 Cable Gland For Ship, 1 Waterproofing Plate, 1 Vertical Type Main Body Packing, 2 Crimping Terminals |
| Gross Weight |
25 kg (55 lbs) |
35 kg (77 lbs) |
24 kg (53 lbs) |
29 kg (64 lbs) |
| Dimensions LxWxH (mm) |
510 × 280 × 290 |
585 × 315 × 330 |
520 × 280 × 270 |
570 × 275 × 285 |
| Packing Unit |
1 |
